Flame Retardant ABS Filament for Electronic Housings & Automotive Components and Safety-Critical Applications
Flame Retardant ABS Filament for Electronic Housings & Automotive Components and Safety-Critical Applications
Couldn't load pickup availability
✔ Ships from China Warehouse via Global Special Line
✔ Tracking provided for all orders
✔ Free Global Shipping on orders over $99
✔ Standard delivery time: 7–12 business days (US/EU)
Engineer with Confidence. Meet Safety Standards with Flame Retardant ABS Filament.
When your application can't compromise on safety, you need a material that provides a critical line of defense against fire. Our Flame Retardant ABS Filament is specially formulated to resist ignition and self-extinguish, making it the ideal choice for manufacturing components where fire safety is paramount. Don't just print a part—print a safer solution.
Why Choose Our Flame Retardant ABS?
· Enhanced Fire Safety
The material is designed to inhibit flame spread and extinguish itself once the ignition source is removed, significantly reducing fire risk in your applications.
· Industrial-Grade Performance
Retains the excellent mechanical strength, durability, and heat resistance of high-quality ABS, ensuring your safety-critical parts are also robust and long-lasting.
· Reliable, Bubble-Free Printing
Manufactured to be 100% bubble-free, guaranteeing consistent diameter, smooth extrusion, and reliable prints without unexpected failures caused by voids.
· Enables Compliant Designs
Allows for the rapid prototyping and low-volume production of parts that need to meet specific flame, smoke, and toxicity requirements for various industries.
Technical Specifications
| Parameter | Specification |
|---|---|
| Filament Diameter | 1.75 mm ± 0.03 mm |
| Nozzle Temperature | 230 - 260 °C |
| Bed Temperature | 100 - 120 °C |
| Bubbles | 100% Bubble-Free |
| Net Weight | 0.8 kg / roll |
| Approx. Length | ~308 meters |
Ideal Applications for Flame Retardant ABS
This filament is critical for components where fire resistance is a key design requirement:
· Electronics Enclosures: Housings for power supplies, chargers, control units, and internal server components.
· Automotive Interiors: Non-structural parts within the cabin and engine bay where specific flame retardancy is needed.
· Electrical Components: Junction box covers, cable management ducts, and sensor holders.
· Prototype Compliance Testing: Creating parts for initial safety and standards certification processes.
Optimal Printing Guidelines
To achieve the best results with this engineering-grade material, we recommend:
· Use an Enclosed Printer: An enclosure is highly recommended to maintain a stable, high-temperature environment, drastically reducing warping and improving layer adhesion for large ABS prints.
· Ensure Strong Bed Adhesion: Use a heated bed (100-120°C) with a proven adhesive such as ABS slurry, PVAc glue (e.g., Dimafix), or a PEI spring steel sheet.
· Ventilate Your Printing Area: As with all ABS filaments, printing in a well-ventilated space or using an air filtration system is advised to manage fumes.
· Keep Filament Dry: Store in a dry place and consider drying before printing (70-80°C for 2-4 hours) for optimal performance, especially in humid environments.
Frequently Asked Questions
Q: What is the flame retardancy standard for this material (e.g., UL94)?
A: This filament is formulated to achieve a UL94 V-0 rating, which is a widely recognized standard for flammability of plastic materials. This indicates its high ability to self-extinguish within seconds in a vertical burn test. Please contact us for specific certification details.
Q: Is it safe to print this material indoors?
A: While the printed part is flame retardant, the printing process itself for ABS typically produces fumes that should not be inhaled. We strongly recommend printing in a well-ventilated area or using a printer enclosure with an air filtration system to capture particulates and volatile organic compounds (VOCs).
Q: Why is the net weight 0.8kg instead of 1kg?
A> The specialized additives used to achieve the flame retardant properties can increase the material's density. To maintain the standard ~300+ meter length and ensure optimal performance, we supply it in a 0.8kg spool. You are still receiving a full length of filament for your projects.
